Filtration devices ECOFIL SN MICRO series consist of one aluminum filter housing, equipped with pump and motor. This allows the oil cleaning independently of hydraulic, automotive or lubricating systems without using the operating pressure.
SN MICRO – series are in a portable or mobile version. SN MICRO - series are recomended for filtering small volume of oil (gearboxes, robots, windmill, etc.).
| Oil tank volume | max. 50 liters |
| El. motor | 50 W BLDC |
| Normal flow volume | 0.18 liters / min. |
| Max. pressure | 8 Bar |
| Oil tank volume | max. 300 liters |
| El. motor | 100 W BLDC |
| Normal flow volume | 1,2 liters / min. by (46cSt/40°C) |
| Max. pressure | 8 Bar |
| Oil tank volume | max. 500 liters |
| El. motor | 180 W BLDC |
| Normal flow volume | 1,8 liters / min. by 2200 rpm (46cSt/40°C) |
| Max. pressure | 8 Bar |
