| Oil tank volume | max. 5000 liters |
| El. motor | 1,0 kW |
| Normal flow volume | 24 liters / min. |
| Max. pressure | 8 Bar |
| Input and output | G 3/4 " |
| Number of filltration units | 9 pcs |
| Suction filter of pump protection | 1 pc 100 µm |
| Achieved purity class | NAS 5/6 |
| Achieved max. volume of water in oil after filtration | 100 p.p.m. |
| After drying of elements lower than | 10 p.p.m. |
| Number of filtration elements | 8 pcs |
| Max. operating temperature | 80 °C |
| Viscosity | 6 - 400 cSt |
| Dimensions (length x height x width) | 1160 x 500 x 950 mm |
| Connection to electricity | 230V or 3x230V/400V (50Hz 100V / (60hz); 3x110 3x220V/440V (60Hz) |
